ZH1.5mm Wafer Pin Header Vertical SMT 2P

Small 1.5mm Pitch for Compact PCB Layouts

The ZH1.5mm wafer Pin Header is built for applications where PCB space is tight. With a 1.5mm pitch and 2-pin configuration, it keeps the connection area small and tidy, making it a good fit for compact electronic boards and internal wiring.

The vertical structure also keeps the connection direction clear on the PCB. For projects that only need two positions, there is no need to use a larger Connector than necessary. This smt Wafer Pin header Connector 2p provides a simple way to handle small board-to-wire connections.

Product Specifications

Vertical SMT Mounting for Faster Assembly

This 2-pin connector is designed for vertical SMT mounting, so it can be placed directly onto the PCB during automated assembly. The reel packaging makes it easier to feed the parts into production equipment, which is especially useful when the same connector needs to be assembled in larger quantities.

The contacts are made from brass with tin plating. The connector is rated at 1A and 100V, with an operating temperature range of -25°C to +85°C. These specifications cover many everyday electronic applications where a small, straightforward PCB connection is needed.

Simple 2-Pin Connection for Everyday Electronics

The wafer Housing Connector 2p is a practical choice when a project needs only two connection points. Its small footprint leaves more room for Other components on the PCB, while the vertical arrangement keeps the finished board neat and easy to work with.

If you are looking for related components, Wafer Housing Terminal products can be used for other terminal connection requirements. You can also Buy Wafer Terminals in different specifications when a project calls for another pitch or pin count. For customers comparing different board-side options, the Wafer Pin Header range provides more choices for compact connection designs.
